Item

Specification

Nozzle inner diameter

6.5mm

Length

200+10mm

Test inclination angle

20,45,90 degrees with manual switching

Flame height

adjustable from 20mm to 175mm

Flame application time

adjustable from 0-999.9s+0.1s

Afterflame time

0-999.9s+0.1s,automatically recorded, manually paused

Afterbum time

0-999.9s+0.1s,automatically recorded, manually paused

Combustion gas

98% methane gas or 989 propane gas (usually liquefied petroleum gas can be used as a substitute)

Flow and pressure

flow meter and U-shaped pressure gauge

Test background

black background

Test process

manual control of the test program, independent ventilation

Chamber volume: 0.5 cubic meters (standard 0.5 cubic meters, 20 cubic meters customizable)

Chamber volume

0.5 cubic meters (standard 0.5 cubic meters, 20 cubic meters customizable)

Cabinet material

mirror stainless steel

Equipment dimensions

1000mm x 650mm x 1300mm(L*W*H)
